BAT400D
Document number: DS30182 Rev. 15 - 2
1 of 3
www.diodes.com
June 2008
? Diodes Incorporated
BAT400D
0.5A SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
Features
?
Low Forward Voltage Drop
?
High Conductance
?
Lead, Halogen and Antimony Free, RoHS Compliant
"Green" Device (Notes 3 and 4)
?
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
?
Case: SOT-23
?
Case Material: Molded Plastic.
UL Flammability Classification
Rating 94V-0
?
Moisture Sensitivity: Level 1 per J-STD-020D
?
Terminals: Solderable per MIL-STD-202, Method 208
?
Lead Free Plating (Matte Tin Finish annealed over Alloy 42
leadframe).
?
Polarity: See Diagram
?
Marking Information: See Page 2
?
Ordering Information: See Page 2
?
Weight: 0.008 grams (approximate)
TOP VIEW
Top View
Device Schematic
Maximum Ratings
@TA
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
VRRM
VRWM
VR
40
V
RMS Reverse Voltage
VR(RMS)
28
V
Average Rectified Current (Note 2)
IO
0.5
A
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave superimposed on rated load
IFSM
3
A
Thermal Characteristics
Characteristic
Symbol
Value
Unit
Power Dissipation (see Figure 1) (Note 2)
PD
480
mW
Typical Thermal Resistance, Junction to Ambient Air (Note 2)
RθJA
286
°C/W
Operating and Storage Temperature Range
TJ, TSTG
-40 to +125
°C
Electrical Characteristics
@TA
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
Reverse Breakdown Voltage (Note 1)
V(BR)R
40
?
?
V
IR
= 1mA
Forward Voltage
VF
?
285
480
300
550
mV
IF
= 10mA
IF
= 500mA
Reverse Current (Note 1)
IR
?
?
1.0
2.0
30
50
μA
μA
VR
= 10V
VR
= 30V
Total Capacitance
CT
?
?
125
20
?
?
pF
pF
VR
= 0V, f = 1.0MHz
VR
= 10V, f = 1.0MHz
Notes: 1. Short duration pulse test used to minimize self-heating effect.
2. Part mounted on FR-4 board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
3. No purposefully added lead. Halogen and Antimony Free.
4. Product manufactured with Data Code V9 (week 33, 2008) and
newer are built with Green Molding Compound. Product manufactu
red prior to Date
Code V9 are built with Non-Green
Molding Compound and may contain Halogens or Sb
2O3
Fire Retardants.
